Motor car engine ZMZ-4062.10

Gasoline, 4-cylinder in-line injection engine.

This is an up-to-date high-speed powerful engine which is widely used on vehicles of domestic manufacture. It provides high acceleration speed characteristics and is equipped with cast iron cylinder block, 4-valve gas distribution system per cylinder and diaphragm clutch.

The engine requires professional maintenance due to the complex fuel supply system and electronic control system.

The engine is designated for installation on middle-class cars.

Clutch:		Electrical equipment:
Type Drive	diaphragm hydraulic	rated voltage 12 V



TECHNICAL PARAMETERS
Usability
Number of cylinders	4
Displacement, I	2,28
Compression ratio	9,3
Rated capacity with revolutions min1, kW(hp)	106,6(145) 5200
Maximum torgue with revolutions min1, Nm (kgm)	200,9(20,5) 4000-4500
Minimum specific fuel consumption, g/kWh (g/hph)	265 (195)
Cylinder bore and pistone stroke,mm	92x86
Weight, kg	192
Engine type	Gasoline inject
Ecological standard	Rules EEK OON (Euro 0)
